2000 mazda mpv vss wire


Post ReplyPost New Topic
< Prev Topic Next Topic >
bklynsoulja
Member - Posts: 4
Member spacespace
Joined: November 13, 2014
Posted: November 13, 2014 at 10:52 PM / IP Logged
hey guys I am trying to locate my vss wire and done some research but cannot read this wiring diagram. Can anyone help me? This what i got so far.
according to this site: http://forum.mpvclub.com/viewtopic.php?t=4963&highlight=vss
"For 00-01 MPV
http://www.mobile.sony.co.jp/sony/result.cgi?YEARS=799&SEND=%81@%82n%82j%81@
Page 1. Item 1.
Page 4. Item 5. The first diagram
Connector of VSS: 16P,No.15, GREEN/ Red"
while that information is for right hand drive mpv, can anybody confirm it the right color wire?
I am looking at the chart show below, it seems like the vss wire comes from the computer and spread to the speedometer and cruse control module. also i circle 3 colors for 3 possible wires that it can be the vss wire, but i am leaning towards more to G/R (red circle on picture) can that be right? and if so it looks like i can get it from the cruise control module or behind the speedo. any advice reading this would be grateful.
2000 mazda mpv vss wire -- posted image.
bklynsoulja
Member - Posts: 4
Member spacespace
Joined: November 13, 2014
Posted: November 13, 2014 at 10:55 PM / IP Logged
can't seem to attach photo so here a link
http://tinypic.com/r/mblm5d/8
