2014 Nissan Maxima Stereo Wiring


Post ReplyPost New Topic
< Prev Topic Next Topic >
jerrycarter
Member - Posts: 1
Member spacespace
Joined: July 30, 2015
Posted: July 30, 2015 at 8:15 AM / IP Logged
Hi, I am needing to know what color is positive and negative wire from the factory amp to the rear deck speakers of my 2014 Maxima. The wire colors are left blue and yellow and right is brown and red. All four wires have some silver marks on them as well.
cutter122
Member - Posts: 16
Member spacespace
Joined: January 08, 2014
Location: Quebec, Canada
Posted: August 17, 2015 at 11:00 PM / IP Logged
2014 Nissan Maxima Stereo Wiring -- posted image.
i am an idiot
Platinum - Posts: 13,666
Platinum spaceThis member consistently provides reliable informationspace
Joined: September 21, 2006
Location: Louisiana, United States
Posted: August 18, 2015 at 3:24 PM / IP Logged
Since the colors you have are not matching up with the colors of the diagram provided, you may have to do it the old fashioned way. Take a 9 volt battery and solder some speaker wires to it. Make sure to get the positive wire on the positive terminal of the battery. Unplug the wires from the speaker, now take the wires you soldered to the battery and touch them to the 2 wire connections of the speakers. When the speaker moves toward the cabin of the vehicle this tells you that the positive terminal of the battery is connected to the positive speaker terminal. If the speaker moves away from the cabin, the wires are backwards. Do this with both to determine polarity.
