Topic: relay wiring

Posted By: parttime
Subject: relay wiring
Date Posted: January 25, 2007 at 10:19 PM

ok i dont know a whole lot about relays but i know why i need one, current draw to high for a normal switch. I need help on how to wire somthing up.

what i want to do is run a 12 volt accesory and it needs to have an activation switch, and momentary push button. so i need a toggle to turn the system on and once its armed/activated (not running) a momentary to complete everything and make it turn run while the button is pushed in. sorry if the explnation was confusing if it was let me know and ill try to clear it up and thanks in advance for any help...

-------------
""You're not ready for the dunes until you're sittin on phat chrome" - Pimp my ride"

Replies:

Posted By: hotwaterwizard
Date Posted: January 28, 2007 at 11:42 PM

A little confusing but I think I understand what you want.

A switch provides power to the circuit. Then a push switch in series with the power switch to activate it when a door or trunk is closed. then power is switched on to the main load.

posted_image

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: parttime
Date Posted: January 29, 2007 at 8:04 PM

ok i thought about it again and came up with this... (by the way this is for an injector that will mist an intercooler with water...) if this is wrong please let me know

-------------
""You're not ready for the dunes until you're sittin on phat chrome" - Pimp my ride"

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 9:00 PM

posted_image

Two Grounds and No HOT

This will not work!

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: parttime
Date Posted: January 29, 2007 at 9:37 PM

ok thanks for letting me know that is what someone else recomended to me, i looked at it and it seemed to work, should i use your design ?

-------------
""You're not ready for the dunes until you're sittin on phat chrome" - Pimp my ride"

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 9:41 PM

My Design both switches in series will cause the relay to activate.

Your Design will work if you put a Hot to one of the switches and a ground to the other.

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: parttime
Date Posted: January 29, 2007 at 9:55 PM

ok so what would i need to change for mine to work?

-------------
""You're not ready for the dunes until you're sittin on phat chrome" - Pimp my ride"

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:02 PM

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:06 PM

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:27 PM

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: parttime
Date Posted: January 29, 2007 at 10:30 PM

alright thanks for the help. is there an advantage to doing it either way?

-------------
""You're not ready for the dunes until you're sittin on phat chrome" - Pimp my ride"

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:33 PM

same either way no advantage to either one

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: wirewise
Date Posted: January 29, 2007 at 10:34 PM

Guys, please limit the width of your images to 640 pixels wide. Thanks!

~wirewise~

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:37 PM

So what you are telling us is to post pictures that are so small you can't see details.
posted_image

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:41 PM

Why does it matter anyways.

I moderate other boards and I have never limited pictures to a small size.

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: wirewise
Date Posted: January 29, 2007 at 10:44 PM

640 pixels wide is plenty. Many of the images you guys posted in this thread had more white space than content. The image below is 640 pixels wide.

posted_image

~wirewise~

Posted By: hotwaterwizard
Date Posted: January 29, 2007 at 10:48 PM

Point taken I will try

-------------
John DeRosa (Hotwaterwizard)
Stockton California
When in doubt, try it out !

Posted By: wirewise
Date Posted: January 29, 2007 at 10:51 PM

hotwaterwizard wrote:

Why does it matter anyways.

I moderate other boards and I have never limited pictures to a small size.

Going too far beyond this as you have in this thread makes for unfriendly browsing for people viewing at 1024x768. All you needed to do was crop your image instead of including white space that accounts for more than half the image width.

~wirewise~
