seabeebuggy

Member - Posts: 2

Joined: January 25, 2018

Location: Nevada, United States

Posted: January 25, 2018 at 3:29 PM / IP Logged

I'm trying to install a auto start in a 1986 Chevy diesel Blazer D10, like a K5 but diesel.

Back to Top

i am an idiot

Platinum - Posts: 13,667

This member consistently provides reliable information

Joined: September 21, 2006

Location: Louisiana, United States

Posted: January 26, 2018 at 10:19 AM / IP Logged

Wiring For 86 Chevy Blazer Diesel -- posted image.

Power lock is covered by flash.

Back to Top

seabeebuggy

Member - Posts: 2

Joined: January 25, 2018

Location: Nevada, United States

Posted: February 02, 2018 at 9:19 AM / IP Logged

thank you. do you now what the info is where the flash blurred out?

Back to Top

geepherder

Platinum - Posts: 3,668

Joined: October 27, 2003

Posted: February 02, 2018 at 5:00 PM / IP Logged

Orange should be accessory, light blue should be power lock.

My ex once told me I have a perfect face for radio.
