How to Wire 528T with OEM Remote Keyless Entry? 2011 Chevrolet Silverado


Post ReplyPost New Topic
< Prev Topic Next Topic >
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: February 27, 2021 at 10:13 PM / IP Logged Link to Post Post Reply Quote jorgegutz
hello, im the new kid in town and looking for guidance on how to wire a 528T pulse timer with my OEM remote keyless entry. i recently replaced my side view mirrors with a power folding mirrors. i am currently using a DPDT switch to unfold and fold them. i have 2 528T's, one for LOCK and the other for UNLOCK. i would like to utilize my keyfob so when i hit LOCK my mirrors FOLD and if i hit UNLOCK on my keyfob my mirrors UNFOLD. it is for my truck, 2011 silverado LT. see attached 2011 silverado power lock diagram.
JG How to Wire 528T with OEM Remote Keyless Entry? 2011 Chevrolet Silverado -- posted image.
jorgegutz
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: March 04, 2021 at 4:25 PM / IP Logged Link to Post Post Reply Quote jorgegutz
any inputs?
jorgegutz
kreg357
Platinum - Posts: 7,431
Platinum spaceThis member has made a donation to the12volt.com. Click here for more info.spaceThis member has been recognized as an authority in Electrical Theory. Click here for more info.spaceThis member has been recognized as an authority in Mobile Security and Convenience. Click here for more info.spacespace
Joined: January 30, 2009
Location: New York, United States
Posted: March 04, 2021 at 5:07 PM / IP Logged Link to Post Post Reply Quote kreg357
OK, you want a door lock to fold the mirrors in and an Unlock will unfold the mirrors.
First question - When you start the truck and shift into drive, do the doors automatically lock? That could mess things up for you.
The unfold with an unlock seems to be OK, so the 528T can be used for that.
Do you presently have to hold your DPDT switch until the mirrors go into position or is it a momentary press?
How are the folding mirrors currently wired to the DPDT switch?
Soldering is fun!
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: March 04, 2021 at 5:21 PM / IP Logged Link to Post Post Reply Quote jorgegutz
that is correct, door locks when on Drive and to manually fold them i just flip my switch and vice versa to unfold them via DPDT switch.
is it ideal to use door lock switch (- input to BCM) wires ( Tan/Gray) as my trigger for fold-unfold or use wires (Lt Blu/ White) fOR Lock-Unlock Ctrl output to PCB Lock-Unlock Relay?
jorgegutz
kreg357
Platinum - Posts: 7,431
Platinum spaceThis member has made a donation to the12volt.com. Click here for more info.spaceThis member has been recognized as an authority in Electrical Theory. Click here for more info.spaceThis member has been recognized as an authority in Mobile Security and Convenience. Click here for more info.spacespace
Joined: January 30, 2009
Location: New York, United States
Posted: March 04, 2021 at 5:41 PM / IP Logged Link to Post Post Reply Quote kreg357
It is probably a better idea to use the Lock and Unlock motor wires as the 528T trigger. These are (+) signals. Here is the info :
Lock Motor             gray (except premium models)     5 wire     dash fuse box, gray 14 pin plug, pin A3 or A7
Driver Unlock Motor        tan (except premium models)     5 wire     dash fuse box, gray 14 pin plug, pin A5 or B4
I was thinking that a PAC TR-7 with a relay might work for the fold-in. You could set it for a double Lock pulse. That way you would do a double lock on the factory remote as you left the truck to fold in the mirrors and the single lock that happens when you shift into Drive won't make the mirrors fold in.
Soldering is fun!
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: March 04, 2021 at 6:02 PM / IP Logged Link to Post Post Reply Quote jorgegutz
that makes more sense! what youre suggesting as far as how i want to fold unfold mirrors with doors locks on Drive is to use PAC TR-7 to FOLD Mirror set to 2 Pulses with relay and use Lock on DRIVE to Unfold mirrors out, and use Driver Lock-Unlock motor for my trigger.
thanks kreg357!
jorgegutz
kreg357
Platinum - Posts: 7,431
Platinum spaceThis member has made a donation to the12volt.com. Click here for more info.spaceThis member has been recognized as an authority in Electrical Theory. Click here for more info.spaceThis member has been recognized as an authority in Mobile Security and Convenience. Click here for more info.spacespace
Joined: January 30, 2009
Location: New York, United States
Posted: March 04, 2021 at 6:09 PM / IP Logged Link to Post Post Reply Quote kreg357
Yep. One PAC TR-7 with relay triggered by a double pulse on the Lock Motor wire for fold-in and one 528T triggered by Unlock Motor wire for unfold.
Any possible issues with the unfolded mirrors getting another unfold pulse?
Soldering is fun!
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: March 04, 2021 at 6:15 PM / IP Logged Link to Post Post Reply Quote jorgegutz
good question, i cant think of one.
jorgegutz
jorgegutz
Member - Posts: 7
Member spacespace
Joined: February 22, 2021
Location: Minnesota, United States
Posted: March 08, 2021 at 6:57 PM / IP Logged Link to Post Post Reply Quote jorgegutz
I got my power folding mirrors working with my keyfob. Thanks Kreg357! I wiired my mirrors with 528T to UNFOLD my mirrors and PAC TR-7 with a Relay to FOLD in andset with 2 pulses and its working great!
Thanks for helping out!
jorgegutz
kreg357
Platinum - Posts: 7,431
Platinum spaceThis member has made a donation to the12volt.com. Click here for more info.spaceThis member has been recognized as an authority in Electrical Theory. Click here for more info.spaceThis member has been recognized as an authority in Mobile Security and Convenience. Click here for more info.spacespace
Joined: January 30, 2009
Location: New York, United States
Posted: March 08, 2021 at 8:15 PM / IP Logged Link to Post Post Reply Quote kreg357
Great news, good work. 👍 Programming a PAC TR7 can be a PITA sometimes.
